TitleBuilding Plan for W. A. M. Bowman - Mt Byron via Esk - OriginalDescription

Building Plan for the Proposed Residence for W. A. M. Bowman Esq. located at Mt. Byron via Esk, Queensland.

J. R. Hughes Plan No. 24652.

Refer also to J. R. Hughes Collection Blueprint MBMP-0019-206.

CreatorHughes, James RobertCollectorHughes, James RobertRecord typeBuilding PlanFormat typePlanFormat descriptionCondition: GoodScale1/8" = 1 FootDimension660mm (w) x 449mm (h)Item statusOriginalLanguageEnglish

REFERENCE

Reference numberMBMP-0019-123

PART OF

CollectionJames Robert Hughes architectural drawings, ca. 1940-1960

CONNECTIONS

STORAGE LOCATION

Storage locationRedcliffe Map Cabinet 4 - Drawer 10

ACCESS

Access restrictionsRestrictedRestrictions on useRestrictions varyCopyright appliesConditions of useAccess to the physical copy is only via discussion with Library staff. Moreton Bay Libraries provides access to these resources for research only.
