Building and Site Plan for L. J. Hansen - Sorrento Street Margate - Blueprint

DETAILS

TitleBuilding and Site Plan for L. J. Hansen - Sorrento Street Margate - OriginalDescription

Building and Site Plan for Proposed Additions to the Dwelling for L. J. Hansen Esq. located at Sorrento Street Margate, Queensland on Subs 106 & 107 of Portion 117 Parish of Redcliffe.

J. R. Hughes Plan No. 21250.

Refer also to J. R. Hughes Collection Original MBMP-0019-108.

Dateca. July 1952CreatorHughes, James RobertCollectorHughes, James RobertRecord typeBuilding PlanFormat typePlanFormat descriptionCondition: GoodScale1/8" & 1/16" = 1 FootDimension525mm (w) x 361mm (h)Item statusBlueprintLanguageEnglish

REFERENCE

Reference numberMBMP-0019-197

PART OF

CollectionJames Robert Hughes architectural drawings, ca. 1940-1960

CONNECTIONS

STORAGE LOCATION

Storage locationRedcliffe Map Cabinet 4 - Drawer 9

ACCESS

Access restrictionsRestrictedRestrictions on useRestrictions varyCopyright appliesConditions of useAccess to the physical copy is only via discussion with Library staff. Moreton Bay Libraries provides access to these resources for research only.
